DGT / DGT60 / DGTQ / DGTP
27
3) Select the number of the connected cells
Select number of scales (in other words, the number of channels, from 1 to 4) connected to the indicator:
SEtuP >> ConFiG >> nChan >> 1..4 and press PRINT.
4) Select the cell to be calibrated
Select the scale to be calibrated (in other words the channel number, from1 to 4):
SEtuP >> ConFiG >> Chan >> 1..4 and press PRINT.
5) Select the step SEtuP >> ConFiG >> CALib and press PRINT.
6) Setting Total Capacity or 1st Range
Select the "rAnGE1" step and press PRINT;
Set the total capacity of the scale or the first range in case of multirange functioning.
The keys take on the following functionalities:
ZERO Decreases the selected digit (blinking).
TARE Increases the selected digit (blinking).
MODE Selects the digit to be modified (blinking), from left to right.
C Quickly zeros the displayed value.
7) Setting of the 2nd Range capacity
Select the "rAnGE2" step (only in case of dual range scale) and press PRINT;
Set the capacity of the second range and press PRINT.
8) Minimum Division
Select the "diV" step and press PRINT;
Set the scale’s minimum division or the first range in case of dual range and press PRINT (selectable values:
1, 2, 5, 10, 20, 50).
Note: the settable division refers to the FIRST RANGE. With the second range the following division is set.
For example, by setting diV=2 , the second range will have diV=5
(!) 1
9) Number of Decimal digits
Select the "dECi" step and press PRINT;
The selectable values are 1.0 (one decimal), 1.00 (two decimals), 1.000 (three decimals), 100000 (no
decimal); confirm with PRINT.
(!) 1.000
10) Unit of Measure
Select the "u.M." and press PRINT.
Set the unit of measure (g, Lb, t, kg) and press PRINT.
(!) kg
11) Select the "CALib.P" step and press PRINT.
12) Select the "ntP" step and press PRINT.
13) Nr. of Calibration points
Set the number of points with the ZERO or TARE keys on which one wants to make the calibration (from 1 to
3, with 1 one will make the zero point and a weight point) and press PRINT.
14) Acquisition of Scale Zero
Select the "tP0" step (scale zero point): unload the scale and wait a few seconds; then press PRINT.
15) Setting of 1st Sample Weight
Select the "ddt1" step (setting of first sample weight); press PRINT, enter the weight value and confirm with
PRINT.
16) Acquisition of 1st Sample Weight
Select the "tP1" step (acquisition of first sample weight): put the weight on the scale, wait a few seconds and
press PRINT.
17) If a calibration point had been set, once the weight acquisition has been made, the display shows for an
instant the value of the internal divisions and then the "ntP" step (or "EqUAL" for the procedure of calibration
4.2).
18)
If there are more calibration points, repeat the operations for the points "ddt2", "tP2", "ddt3", "tP3".
Once the weight acquisition is made, the display shows for an instant the value of the internal divisions and
then the "ntP" step (or "EqUAL" for the calibration procedure 4.2).
19) If a single scale is connected to the instrument (nChan = 1) >> Go to point 19)
If there are various scales connected to the instrument (nChan > 1) >> Repeat the calibration procedure
for each scale, starting from point 3) in order to select the scale to be calibrated (go through again the steps
