DGT / DGT60 / DGTQ / DGTP
79
•
PRN SERIAL PORT COM 2
6. TX Transmission
7. RX Reception
8. GND GND
• PROFIBUS FEMALE CONNECTOR (DGTQ PB version)
3. B-LINE
5. GND BUS
6. +5VBUS
8. A-LINE
• INPUTS (OPTOISOLATOR PHOTOCOUPLERS) (for all the versions)
The maximum voltage applicable to the inputs is between 12 ÷ 24 Vdc with current from minimum 5 mA to maximum
20 mA.
