VEVOR MX-S716G - SPECIFICATIONS

- 8 -
SPECIFICATIONS
Technical parameter：
Model
MX-S716G
Drive Type
Direct drive motor, no belt drive, Metal gear
Input Power
EU
220V-240V/50 Hz
AUS
220V-240V/50 Hz
US
110V/60 Hz
Rated Power
800W
Material Compatibility
Wood, Plastics, Soft Metals (Brass, Copper,
Aluminium, etc.)
Swing over Bed
200 mm
Swing over Cross Slide
110 mm
Bed Width
80 mm
Tool Post Type
4 Way
Max. Compound Slide Travel
80mm
Max. Cross Slide Travel
75 mm
Tailstock Spindle Travel
60 mm
Tailstock Taper
MT2
Spindle Taper
MT4
Range of Metric Threads
0.5–3 mm
Range of Imperial Threads
10–44 TPI
Range of Longitudinal Feed
0.1–0.2 mm
Centre Distance
400 mm
Chuck Diameter
100
Spindle Bore Diameter
32 mm
Max. Spindle Speed
150-2500 RPM ±10%
Product Dimensions
960 x 490 x 530 mm
Weight
N.W.:44 kg
G.W.:56 kg
