VEVOR S1610 - Parts List

1.Parts List
Part No Part Name Eplanation Quantit Picture Part No Part Name Eplanation Quantit Picture
01 Aluminum profile 20100*160mm 1
02 Aluminum profile 2020*220mm 6
03 Aluminum profile 2020*235mm 2
04 Right angle connector 2028 12
05 Right angle connector 2040 2 A3 T8 Nut (Z T8*15mm 1
06 X Smooth ais 10*260mm 2 A4 Z Lead scre T8*88mm 1
07 Y Smooth ais 10*235mm 2 A5 Z Smooth ais 8*92mm 2
08 X Lead scre T8*263mm 1 A6 Stepper motor 42HD 1
09 Y Lead scre T8*230mm 1 A7 Inner heagon scre M3*10 4
10 Support for smooth ais SK10 8 A8 Spindle motor 775 1
A9 Inner heagon scre M4*30 1
A10 Square Nut M4*2.5mm 1
A11 Inner heagon scre M3*18 4
14 Muff coupling(Z 8-5 1 Set
11 T8 Nut (X/Y  2 19 Spring 10.5 1
12 Stepper motor 42HD 2
13 Mounting for motor 3mm 2 Part No Part Name Eplanation Quantit Picture
14 Muff coupling (X/Y 8-5 2 Set C1 Control board VIGO 1
15 X-bearing support seat Flange bearings 1 C2 Column PA,M5*3 4
16 Nut support seat (Y) T8 1 23 Inner heagon scre M5*10 4
17 Y-bearing support seat  1 26 Ship nut M5-10 4
18 Guide block (Y)  4 C3 Stepper motor ire 4P 3
19 Spring 10.5 2 C4 Spindle motor ire 2P 1 
20 Hand knobX/Y 8mm 2
21 Hand knobZ 5mm 1
22 Coerplate  6 C6 USB cable  1 
23 Inner heagon scre M5*10 51 C7 Poer suppl 24V,5A 1
24 Inner heagon scre M5*8 14
25 Inner heagon scre M3*6 8 Part No Part Name Eplanation Quantit Picture
26 Ship nut M5-10 47 L1 Laser kit Optional 1 Set 
27 Trapeoidal nut M5-20 18 L2 Laser ire 3P 1 
L3 Protectie glass Optional 1
29 Set Scre for knob M4*5 3
30 ER11 C16-ER11-35L 5mm 1Set Part No Part Name Eplanation Quantit Picture
31 Milling cutter 3.175 1 Set 32-1 Pressing plate 50*20 4 PCS
32 Fiture  4 Set 32-2 Scre M6*40 4 PCS
33 Inner Heagon Wrench 2/2.5/3/4mm 1 Set 32-3 Scre M5*45 4 PCS
34 Nut Wrench 14# / 17mm 1 Set 32-4 Butterfl nut M5 4 PCS
35 Soft brush  1 32-5 Washer M6*2mm 4 PCS
36 U Disk  1
A1  1
A2 Guide block (Z)  1
Guide block (X)
1610 Parts List Component A ( Alread assembled )
2/14
24M5*1mmWasher28
Offline controller
and date cable
Control board package
Laser package  Optional 
Fiture33 assembl
Optional
1 Set
C5
Component Alread assembled 1 SetA
32-3
32-
32-2
32-1
32-
S1610 Ver 1.2
