VEVOR S1610 - Page 6

29: M4*5 1PCS
20: Hand knobX
Φ8mm 1PCS
23: M5*10 1Pcs Screw
15: X-bearing 1PCS
26: Ship nut
1PCS
22: Coverplate 6PCS
Step 
12: Stepper motor 1PCS
25: M3*6 screw 4PCS
13: Mounting for motor 1PCS
D
i
r
e
c
t
i
o
n
o
f
c
o
n
n
e
c
t
i
n
g
w
i
r
e
24: M5*8 2PCS Screw
26: Ship nut 2PCS
11
Step
6/14
26: Ship nut 4PCS
C1: Control board 1PCS
C2: Column 4PCS
23: M5*10 4PCS
Screw
The plastic column must
be assembled between
the controlboard and
the aluminum parts.
14: Muff coupling 1PCS
S1610 Ver 1.2
