Mounting of The Handle
Inse the handle socket into the lever pin, then inse the
handle pin into the lever holder, and then align the handle
pin hole with the vel pin, and then the vel pin goes directly
through the handle pin hole.
Handle
Handle xing pin
Tie rod holder
Tie rod pin
Installation of Agitators
It is impoant to ensure that the control power switch is
turned o. Conrm that the display is o. Inse the agita-
tor into the freezer tank and slowly rotate the agitator with
your hands to embed the quad head of the reducer into the
quad connector of the reducer.
Freezing cylinder
Agitator assembly
Installation of Discharge Manifolds
The four mounting holes of the discharge valve are passed
through the four discharge heads to x the bolts, the stem
head is stuck into the lever clamp position, and then the
four fastening nuts are evenly fastened diagonally.
Pull rod
Fastening screws
Outlet valve assembly
Fasten screws
Installation of Discharge Manifolds
The four mounting holes of the discharge valve are passed
through the four discharge heads to x the bolts, the stem
head is stuck into the lever clamp position, and then the
four fastening nuts are evenly fastened diagonally.
Drip tray
Water box hanging board
16
