Chapter 2
2-14
Clear CMOS (J10)
The Clear CMOS jumper allows you to clear the CMOS memory of system
parameter settings. If you want to clear the system configuration, use
the JBAT1 (Clear CMOS Jumper ) to clear data. Follow the instructions
below to clear the data:
The VIA EPIA Mini-ITX Mainboard provides a series of jumpers to set the
computer’s functions. This section explains the functions of all the
mainboard settings.
Clear CMOS
3
1
Normal
3
1
Jumpers
Do not clear the CMOS while the system is on;
it may cause damage to the mainboard.
WARNING!
1-2: Normal
2-3: Clear CMOS
1
3
