Major Parameter
Mode: ALC series,FCD series, FHC series
Division Value: 1～75000 Non-linearity: ≤0.01%F.S
Load cell excitation: 5V DC,5% 100mA
Load cell: 350Ω
Operation keypad: 20
Display: LCD, 6 digits, green backlight
Operating Temperature: 0～40℃；≤85%RH Fuse: 500mA
Power Source: AC 110V/220V (±10%) + DC 6V/4.5AH
Rechargeable Battery
II. Special Remarks
1. Put the scale on a firm level surface for accurate weight
readings.
2. Please use independent AC outlet to avoid the interference of
other electrical appliances; Please don't place anything on the
scale pan while power on.
3. Avoid the machine near the exhaust port of ventilating system.
4. Please warm up the machine 15-20 minutes before operation.
5. All goods weighed should be placed in the centre of the platform
for a accurate weighing. The overall dimensions of the goods
being weighed should not exceed the dimension of the plaster.
