6
HP PLUS TOWER/RACK
USER MANUAL
www.vicidbs.com
Version 1.02.0000
HP PLUS
200 HC
HP PLUS
500 HC
HP PLUS
750 HC
HP PLUS
1000 HC
HP PLUS
2000 HC
HP PLUS
4000 HC
HP Plus Rack
500
Flow mL/min 200 500 750 1000 2000 4000 500
Purity >99.999% 99% >99.999%
Hydrocarbon purity
(measured as methane)
<0.1 ppm
Dewpoint
o
C (
o
F) -50 (-58)
Outlet pressure barg (psig) Up to 5 max (75)
Inlet pressure barg (psig) 7 to 10 (100 to 145)
Actual inlet air requirement
liters @ 8 barg (psig)
11 (159.5) 11 (159.5) 12 (174) 16 (232.1) 20 (290.1) 24 (348.1) 11 (159.5)
Recommended compressor
air inlet @ 8 barg (psig)
22 (319.1) 22 (319.1) 24 (348.1) 32 (494.1) 40 (580.2) 48 (696.2) 22 (319.1)
Pressure drop barg (psig) 1.5 (22)
Inlet air quality Clean dry compressed air ISO8573-1:2010 Class 1.2.1
Technology Carbon molecular sieve
Warm up time minutes 60
LED indicators Power on/off, system ready, errors
Electrical supply 110-120V 60Hz / 220-240V 50 Hz
Power consumption watts 270
Noise level Minimal
Dimensions mm (in) 175W x 490H x 670D (6.9W x 19.3H x 26.4D) 19”W x
3UH x 500D
(19W x 3UH
x 19.6D)
Weight kg (lb) 24.9 (54.9) 28.6 (63) 24.9
(54.9)
25 (55.1)
Shipping dimensions mm (in) 795W x 435H x 630D (31.3W x 17.1H x 24.8D) 720W
x 565H
x 375D
(28.3W x
22.2H x
14.7D)
Shipping weight kg (lb) 28.9 (63.7) 34.5 (76) 28.9
(63.7)
29 (63.9)
Operating temp
o
C (
o
F) 15 to 35 (59 to 95)
Inlet connection 1/4” Compression
Outlet connection 1/8" Compression
Certication CE, FCC, MET
MODELS & SPECS -
With Catalyst
