4. SPECIFICATIONS
HP PLUS
500
HP PLUS
750
HP PLUS
1000
HP PLUS
2000
HP PLUS
4000
Flow mL/min 500 750 1000 2000 4000
Purity >99.999% 99%
Hydrocarbon purity
(measured as methane)
n/a
Dewpoint
o
C (
o
F) -50 (-58)
Outlet pressure barg (psig) Up to 5 (75)
Inlet pressure barg (psig) 7 to 10 (100 to 145)
Actual inlet air requirement
liters @ 8 barg (psig)
11 (159.5) 12 (174) 16 (232.1) 20 (290.1) 24 (348.1)
Recommended compressor
air inlet @ 8 barg (psig)
22 (319.1) 24 (348.1) 32 (494.1) 40 (580.2) 48 (696.2)
Pressure drop barg (psig) 1.5 (22)
Inlet air quality Clean dry compressed air ISO8573-1:2010 Class 1.2.1
Technology Carbon molecular sieve
Warm up time minutes 60
LED indicators Power on/off, system ready, errors
Electrical supply 110-120V 60Hz / 220-240V 50 Hz
Power consumption watts 12
Noise level Minimal
Dimensions mm (in) 175W x 490H x 670D (6.9W x 19.3H x 26.4D)
Weight kg (lb) 22.4 (49.4) 26.1 (57.5) 22.4 (49.4)
Shipping dimensions mm (in) 795W x 435H x 630D (31.3W x 17.1H x 24.8D)
Shipping weight kg (lb) 26.4 (58.2) 32 (70.5) 26.4 (58.2)
Operating temp
o
C (
o
F) 15 to 35 (59 to 95)
Inlet connection 1/4” Compression
Outlet connection 1/8" Compression
Certication CE, FCC
MODELS & SPECS -
Without Catalyst
