NM PLUS HYDROGEN GENERATOR
USER MANUAL
www.vicidbs.com
Version 1.06.0000
5. SPECIFICATIONS
HYDROGEN
FLOW RATE AT STP
STANDARD TEMPERATURE
AND PRESSURE (20°C, 1 BARG)
CELL-TYPE: PROTON- EX-
CHANGE MEMBRANE (PEM)
- 100% TI
CELL PART-NUMBER (PN)
NM Plus 100 0-100 cc/min Cell-pn: DB-Cell-MI
NM Plus 160 0-160 cc/min Cell-pn: DB-Cell-MI
NM Plus 250 0-250 cc/min Cell-pn: DB-Cell-MU1
NM Plus 300 0-300 cc/min Cell-pn: DB-Cell-MU1
NM Plus 400 0-400 cc/min Cell-pn: DB-Cell-MU2
NM Plus 500 0-500 cc/min Cell-pn: DB-Cell-MU2
NM Plus 600 0-600 cc/min Cell-pn: DB-Cell-MU2
NM Plus 1000 0-1000 cc/min Cell-pn: DB-Cell-MU3
NM Plus 1350 0-1350 cc/min Cell-pn: DB-Cell-MU4
MAX OUTLET PRESSURE 11 barg (160 psi)
PURITY 99.99996%+
POWER CONSUMPTION (W)
AND WEIGHT (KG)
NM Plus 100 100 W 14 kg
NM Plus 160 120 W 14 kg
NM Plus 250 165 W 15 kg
NM Plus 300 205 W 15 kg
NM Plus 400 210 W 16 kg
NM Plus 500 220 W 16 kg
NM Plus 600 255W 16 kg
NM Plus 1000 385 W 17 kg
NM Plus 1350 410 W 18 kg
INPUT VOLTAGE 110-120 V / 60 Hz 220-240 V / 50 Hz
FUSE 4A (5 x 20)
PRESSURE ACCURACY 0.1 bar (± 0.5 %)
MICROPROCESSOR
CONTROLLED DISPLAY
Graphic Display- Touch Screen, 128 x 64 pixels
INDEX OF PROTECTION IP2X
OPERATION CONDITIONS:
- TEMPERATURE
- RELATIVE HUMIDITY
15°C to +35°C
0-80%, non condensing
OVER VOLTAGE
CATEGORY
II
POLLUTION DEGREE 2
NOISE LEVEL 46 dB(A)
CASE DIMENSIONS 230w x 370d x 507h mm
