VICI CM-2016 - Page 5

5
3.2.4. AC Voltage (ACVrms)
Range Accuracy Resolution
600mV ±(1.5% of reading + 5) 0.l mV
6V
±(1,0% of reading + 5)
0,001 V
60V 0,01 V
600V 0,1 V
Input impedance: 10MΩ. Overload production: 1000Vrms
Frequency response: 750 V at 40Hz - 1 kHz, other ranges 40Hz - 400Hz.
3.2.5. DC Current (DCA)
Range Accuracy Resolution
600 A (2.0% + 30) 0.l A
NOTE: Clear to zero before measurement. The testing object shall be placed in the
middle of the clamp jaw.
3.2.6. AC Current (TRMS)
Range Accuracy Resolution
600 A (2.0% + 30) 0.l A
Frequency response: Sine wave and triangle wave 40Hz - 1kHz;
other waveforms 40Hz - 200Hz.
NOTE:The testing object shall be placed in the middle of the clamp jaw.
3.2.7. Resistance (Ω)
Range Accuracy Resolution
600 Ω (0.8% + 5) 0,1 Ω
6 kΩ
(0.8% + 3)
1 Ω
60 kΩ 10 Ω
600 kΩ 100 Ω
6 MΩ 1 kΩ
60 MΩ (1.0% + 25) 10 kΩ
Open circuit voltage: <3 V. Over load protection: 250Vrms.
NOTE:
a) In 600 Ω range, short the test leads to measure the wire resistance,
and then subtract it from the real measurement value.
b) When measure resistance over 1 MΩ, it is normaI that the reading reacts slowly.
Please wait until the reading is stable.
WARNING: DO NOT input voltage in this range.
