VICI CM-2016 - Page 6

6
3.2.8. Capacitance (C)
Range Accuracy Resolution
60 nF
(3.5% + 20)
10 pF
600 nF 100 pF
6 µF 1 nF
60 µF 10 nF
600 µF
(5.0% + 10)
100 nF
6000 µF 1 µF
Over load protection: 250Vrms.
WARNlNG: DO NOT input voltage in this range.
3.2.9. Frequency (f)
Range Accuracy Input sensitivity
20 MHz (1.0% + 3) >0.7V
Over load protection: 250 Vrms.
3.2.10. Temperature
Range Accuracy Resolution
-40°C - 1000°C
(1.0% + 5) < 400°C
1°C
(1.5% + 15) ≥ 400°C
0°F - 1832°F
(0.75% + 5) < 750°F
1°F
(1.5% + 15) ≥ 750°F
Sensor: K type banana plug (Nickel-Chromium Nickel-Silicon)
WARNING: DO NOT input voltage in this range.
3.2.11 Diode and Continuity test
Range Display value Testing condition
Diode forward voltage drop
Forward DC current 1mA
Open circuit voltage 3V
When the testing resistance ís less
than (50±20) Ω,the buzzer
alarms continuously
Open circuit voltage 3V
Press SELECT key to switch
between two ranges
Over load protection: 250Vrms.
WARNlNG: DO NOT input voltage in this range.
