Vicon Extra 224 - Page 13

Assembly
13
 Secure the hydraulic hose as shown .

Lift the machine as shown and remove the support.
 Mount the skid .
 Fit the skid.
M12 x 35 (3 pcs.)
ø13-ø24x2,5 (3 pcs.)
M12 Lock Nut (3 pcs.)
