Assembly
14
Fit the guard.
Special for model 232
Fit the guard.
Fit the guard.
M10 x 25
ø10,5-ø20x2
M12 x 45
ø13-ø24x2,5
M10 Lock Nut
M12 Lock Nut
M10 x 25
ø10,5-ø20x2
M10 x 30
ø10,5-ø20x2
M10 Lock Nut
M10 Lock Nut
M10 x 25
ø10,5-ø20x2
M10 Lock Nut
M10 x 19
ø10,5-ø20x2
M10 Lock Nut
