Assembly
17
Secure the tarpaulin.
Fit the pin
.
Fit the lifting pins.
M10 x 19
ø10,5-ø30x2.5
M10 x 25
ø10,5-ø20x2
M10 Lock Nut
M10 Lock Nut
M16 x 110
225 Nm
(165 ft.lbs.)
ø17-ø30x3
M16 Lock Nut
