Vicon Extra 232 - Brace Securing and Pawl Check

Assembly
8
 Secure the brace .

Fit the bracket as shown .
Note the position of the washers .

Check that the pawl is in the position shown .
ø35 x ø21 x 21 (2 pcs.)
ø20 x 90
ø6 x 30
ø12 x 55
ø30.5-ø50x5 (3 pcs.)
