The meaning of the symbols
This symbol indicates tips or additional
information.
This warning triangle indicates important safety
information and dangers. If this is not complied
with, it can lead to:
• Serious errors with the machine's operation.
• Damage to the machine.
• Injury or accidents.
Torque moment
Tightening torque for grade 4.6 - 5.8 - 8.8 - 10.9 -
12.9 black and/or galvanised and ungreased
bolts when tightened on smooth surfaces or plain
washers.
For safety reasons, always use original parts.
Dim.
Bolt grade
4.6 5.8 8.8 10.9 12.9
Nm ft/lb Nm ft/lb Nm ft/lb Nm ft/lb Nm ft/lb
M5 2 1.6 3.5 2.5 5.5 4 8 6 10 7
M6 3.5 2.6 6 4.5 10 7 14 10 17 12
M8 9 6.4 15 10.5 24 17 33 23.5 40 28.5
M10 17 12 29 21 47 33.5 65 46.5 79 56.5
M12 3021.55136.581 5811481.513697
M14 48 34 80 57 128 91.5 181 130 217 155
M16 74 53 123 88 197 141 277 200 333 238
M18 103 73.5 172 123 275 196.5 386 275 463 330
M20 144 103 240 171.5 385 275 541 386.5 649 463.5
M22 194 138.5 324 231.5 518 370 728 520 874 624
M24 249 178 416 297 665 475 935 668 1120 800
