Victa 020856 - Features & Definitions

4
Features & Supplied Items
WARNING
Do not operate the product if any component is missing or damaged. Have any missing or
damaged components repaired or replaced.
1. Handle 10. Gun
2. Nozzles 11. Gun trigger lock
3. Gun holster 12. Gun trigger
4. Detergent bottle 13. Lance
5. hose hanger
6. Water outlet
7. Water inlet
8. Wheels
9. High pressure rubber hose
1
2
3
4
9
10
11
12
13
8
7
6
5
7
6
FEATURES & DEFINITIONS
