I-769N.Preaction/AC-ELEC / Victaulic
®
Series 769N FireLock NXT
™
/ Installation, Maintenance, and Testing Manual
Electric AutoConvert Dry Release
Preaction Trim
The components shaded in orange below are shipped separate from the valve and must be installed in accordance with the trim drawing provided.
NOTE: The Vic-Quick Riser (VQR) assembly is shown.
Electric AutoConvert Dry Release
Preaction Trim with Redundant Solenoid Valve
I-769N.Preaction/AC-ELEC_6 REV_A
