6000counts Pocket Clamp Multimeter
4) It is forbidden to input voltage values exceeding 250V DC or AC peak to avoid damage to the meter.
3-8. Temperature measurement ( °C/°F)
The operation is as follows: (top right)
1. Dial to the“TEMP”file;
2. Insert the two input ends of the temperature probe into the “V/Ω /Hz” and “COM” terminals of the red test pen. The test probe is inserted into
the measured water, and the temperature of the measured water will be displayed on the LCD.
3. Press the SELECT button to toggle between Celsius and Fahrenheit (°C/°F).
Note:
1) It is forbidden to input voltage values exceeding 250V DC or AC peak to avoid damage to the meter.
3-9. Square wave output（ ）
The operation is as follows: (top right)
1 Dial to “ ”; (default starting output is 50Hz);
2. Insert the two inputs of the device under test into the “V/Ω /Hz” and “COM” terminals of the red test pen.
3.Trigger the “ SELECT ” button. The “ V/ Ω /Hz” and “ COM ” terminals of the table respectively output
50Hz-100Hz-200Hz-300Hz-400Hz-500Hz-600Hz-700Hz-800-Hz-900Hz-1000Hz-2000Hz -3000Hz-4000Hz-5000Hz. At the same time, the LCD
screen displays the current output value.
Note:
1) It is forbidden to input voltage values exceeding 250V DC or AC peak to avoid damage to the meter.
3-10. NCV measurement;
The operation is as follows:
1. dial to the “NCV” position; (in the no-measure state LCD displays “EF”);
2. The front end of the meter has NCV test points. As long as the point is close to the AC voltage, the buzzer will emit different continuations
according to the different strength of the signal, and the LCD will also display according to the strength of the signal. Different number of segments.
±（1.0%+5）＜400℃; ±（1.5%+15）≥400℃
±（0.75%+5）＜750℉; ±（1.5%+ 15）≥750℉
