IX. Features
1. General Features
1-1. Display mode: LCD display;
1-2. Max. display: 3999(3 3/4)bit auto polar display or
unit display;
1-3. Measurement mode: Dual slope A/D conversion;
1-4. Conversion rate: 3 times/s;
1-5. Over-range display: “OL” displayed in the highest
1-6. Low battery display: “ ” occurs on the upper part
of the LCD;
1-7. Auto power-off function;
1-8. Max. head opening size: dia. 38mm;
1-9. Max. size of predicted current lead: dia. 36mm;
1-10. Effect of electromagnetic field: If used for devices
nearby electromagnetic field, unstable or incorrect
readings may be displayed;
1-11. Error caused by test position: When measuring
current, please place the source to be tested in the
center of the head; otherwise, certain additional
error will occur;
1-12. Operating environment: (0~40)℃, RH＜80%;
1-13. Storage environment: -10~50℃, RH＜80%;
