Manual 0-4998 PARTS LIST
6-1
SECTION 6:
PARTS LISTS
6.01 Introduction
A. Parts List Breakdown
The parts list provide a breakdown of all replaceable components. The parts lists are arranged as follows:
Section "6.03 Power Supply Replacement"
Section "6.04 Major External Replacement Parts"
Section "6.05 Front Panel Replacement Parts"
Section "6.06 Left Side Replacement Parts"
Section "6.07 Right Side Replacement Parts"
Section "6.08 Options and Accessories"
Section"6.09 ReplacementPartsforHandTorch"
Section"6.10 ReplacementParts-forMachineTorcheswithUnshieldedLeads"
Section"6.11 TorchConsumableParts(SL100SV)"
NOTE
Parts listed without item numbers are not shown, but may be ordered by the catalog number shown.
B. Returns
If a product must be returned for service, contact your distributor. Materials returned without proper authorization will not be
accepted.
6.02 Ordering Information
Order replacement parts by catalog number and complete description of the part or assembly, as listed in the parts list for each
typeitem.Alsoincludethemodelandserialnumberofthepowersupply.Addressallinquiriestoyourauthorizeddistributor.
6.03 Power Supply Replacement
Thefollowingitemsareincludedwiththereplacementpowersupply:workcable&clamp,inputpowercable,gaspressureregula-
tor/lter,andoperatingmanual.
Qty Description Catalog #
1 CutMaster 102 Power Supply
208/230 - 460VAC, Single or 3 Phase, 60Hz,
with 208/230 - 460 VAC single phase input power cable and plug 3-1330-1
with 460 - 208/230 VAC three phase input power cable 3-1330-2
600VAC, 3 Phase, 60Hz,
with 600V, 3 phase input power cable and plug 3-1330-5
