Victoria Arduino EAGLE ONE PRIMA Service Manual

127
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
E
E
EL
L
L
E
E
EC
C
C
T
T
T
TR
R
R
I
IC
C
C
C
C
C
O
OM
M
M
M
M
P
P
P
P
P
O
O
O
O
N
N
N
E
E
E
E
E
N
N
N
N
T
T
T
T
S
S
S
S
S
Right side, “high voltage”:
CN18
power IN (+230VAC).
CN19
10 pins green terminal for pump,
contactor and solenoid valves, see
details below.
FS1
static relay.
FS2
coffee group’s heating element.
FS3
coffee boiler’s heating element.
In details, regarding to CN19, the 10 pins
green terminal:
PIN CABLE COLOUR DESCRIPTION
1
Orange Pump
2
Black
Tank valve
3
Violet
Water stop valve
4
- None
5
Light brown
Easycream air
valve (optional)
6
Yellow Steam valve
7
Red Contactor
8
Brown Self-levelling valve
9
White
Hot and cold
water valves
10
10
Green Coffee valve
NOTE
For further information on electrical
connections, follow electrical diagrams
on Chapter 13.
13
13
14
14
08
