Disconnect the cables from the tank
valve.
4
Utilizing a small screwdriver, unscrew the
two screws that fix the valve to the frame.
5
Utilizing a plier, remove the clip and the
Teflon pipe of the third outlet.
6
Utilizing a vise and a 14 mm wrench, un-
screw the nut and remove the coil of the
valve.
7
If the inspection of the valve is needed,
follow the same procedure described in
paragraph 7.8.1 for the steam valve, by
utilizing a vise and a 14 mm wrench.
