Victory Kingpin - Check Engine Compression; Check Exhaust System

131
MAINTENANCE
Check Engine Compression
An accurate periodic engine compression check documents engine wear and condition. F or engine compression
check procedures and special tools required, see the VICTORY Service Manual or contact an authorized VICTORY
dealer.
Check Exhaust System
Check the exhaust system for stains from leaking exhaust gasses. Replace exhaust gaskets if necessary (see the
VICTORY Service Manual or an authorized VICTORY dealer). Check all exhaust system fasteners.
1. Tighten exhaust header flange nuts.
Torque: 12 ft-lbs (16 Nm)
2. Tighten muffler mounting screws.
Torque: 18 ft-lbs (24.5 Nm)
3. Tighten support bracket nut.
Torque: 35 ft-lbs (47.5 Nm)
4. Tighten muffler clamps.
Torque: 31 ft-lbs (42 Nm)
4
1
1
2
2
3
4
