Charger inverter
-If the LEDs are flashing
alternately, the battery is nearly
exhausted and the nominal
output is exceeded.
-If "overload" and "low battery"
flash simultaneously, the ripple
voltage on the battery
terminals is too high.
mains on
on
inverter on
Bulk
overload
off
absorption
low battery
charger
only
Float
temperature
Charger inverter
The inverter switched off due
to excess ripple voltage on the
battery terminals.
mains on
on
inverter on
Bulk
overload
off
absorption
low battery
charger
only
Float
temperature
Battery Charger
Charger inverter
The AC input voltage is
switched through and the
charger operates in bulk mode.
mains on
on
inverter on
Bulk
overload
off
absorption
low battery
charger
only
Float
temperature
Charger inverter
The mains voltage is switched
through and the charger is on.
The set absorption voltage,
however, has not yet been
reached. (BatterySafe mode)
mains on
on
inverter on
Bulk
overload
off
absorption
low battery
charger
only
Float
temperature
