42
7.3.2 VE.Bus error codes
A VE.Bus system can display various error codes. These codes are displayed with the
"inverter on", "bulk", "absorption" and "float" LEDs.
To interpret a VE.Bus error code correctly, the following procedure should be
followed:
1. Is the "inverter on" LED flashing? If not, then there is no VE.Bus error code.
2. If one or more of the LEDs "bulk", "absorption" or "float" flashes, then this flash
must be in phase opposition to the "inverter on" LED, i.e. the flashing LEDs are off if
the "inverter on" LED is on, and vice versa. If this is not the case, then there is no
VE.Bus error code.
3. Check the "bulk" LED, and determine which of the three tables below should be
used.
4. Select the correct column and row (depending on the "absorption" and "float"
LEDs), and determine the error code.
5. Determine the meaning of the code in the tables below.
Bulk LED off
Absorption LED
off Flashing on
Float LED
off 0 3 6
flashing 1 4 7
on 2 5 8
Bulk LED flashes
Absorption LED
off Flashing on
Float LED
off 9 12 15
flashing 10 13 16
on 11 14 17
Bulk LED on
Absorption LED
off Flashing on
Float LED
off 18 21 24
flashing 19 22 25
on 20 23 26
