4. Technical specifications
PowerControl / PowerAssist
Input voltage range: 95-140VAC; Input frequency: 45 – 65Hz; Power factor: 1
Maximum feed through current
Minimum AC supply current capacity for
PowerAssist (A)
Input voltage range (V DC)
Output voltage: 120 VAC ± 2% Frequency
Cont. output power at 25°C / 77°F (VA) (3)
Cont. output power at 25°C / 77°F (W)
Cont. output power at 40°C / 104°F (W)
Cont. output power at 65°C / 150°F (W)
Zero-load power (W) 20 20
Zero-load power in AES mode (W) 15 15
Zero-load power in Search mode (W) 8 10
64A peak, 45Arms for 1 sec.
Input voltage range: 95-140VAC Input frequency: 45 – 65Hz Power factor: 1
Charge voltage 'absorption' (V DC)
Charge voltage 'float' (V DC)
Charge current house battery (A) (4)
Charge current starter battery (A)
Battery temperature sensor
Max. 32A Switches off when no external AC source available
VE.Bus communication port
For parallel and three phase operation, remote monitoring and system integration
General purpose comm. port
Operating temp.: -40 to +65°C/ -40 - 150°F (fan assisted cooling)
Humidity (non-condensing) : max 95%
Material & Colour: aluminium (blue RAL 5012) Protection category: IP 21
M8 bolts (2 plus and 2 minus connections)
Screw terminals 13mm² (6 AWG)
EN 60335-1, EN 60335-2-29
EN 55014-1, EN 55014-2, EN 61000-3-3
1) Can be adjusted to 50Hz;
2) Protection
a. Output short circuit
b. Overload
c. Battery voltage too high
d. Battery voltage too low
e. Temperature too high
f. 120VAC on inverter output
g. Input voltage ripple too high
3) Non linear load, crest factor 3:1
4) At 25°C ambient
5) Programmable relay which can be set for general alarm, DC undervoltage or genset start/stop function
