Page 14 MNVCSM42A_1511_EN
3.5.4.3 Multiplexer (AUX line)
For the type of Multiplexer to be used, see the following connection tables:
Matrix (AUX line) –Javelin/Hitron Multiplexer RS 485 connection
MATRIX RJ-jack 1 RJ-jack 2 Mux
RS485-A White ----------------- Black RS485-A
RS485-B Yellow ----------------- Green RS485-B
Matrix (AUX line) – SP16C Videotec Multiplexer RS 485 connection
MATRIX RJ-jack 1 RJ-jack 2 Mux
RS485-A White ----------------- Black RS485-A
RS485-B Yellow ----------------- Yellow RS485-B
3.5.4.4 VCR
The Trigger impulse is recognised on the rising or falling edge which can be set at the matrix programming
stage. Connect the VCR input video with output video n°2 of the matrix (VCR dedicated output). For the VCR
trigger on the other hand, refer to the following connection table:
Matrix – VCR connection
Matrix DB15 VCR
Pin 12 – Trigger ------------------------- Trigger pin
Pin 14 – Ground GND ------------------------- Ground pin
