[CAMERA TEXT 1 4.1]
[----------------------------]
[Text O1# ]
[----------------------------]
[1.ABC 2.DEF 3.GHI ]
[4.JKL 5.MNO 6.PQRS ]
[7.TUV 8.WXYZ ]
[ ]
[ENTER.Blank CLEAR.Erase ]
[INC/DEC.Other characters ]
[ ]
[SEQ.End ]
Lovercase characters:
[1.abc 2.def 3.ghi ]
[4.jkl 5.mno 6.pqrs ]
[7.tuv 8.wxyz ]
Numerical/simbol characters:
[1.1O 2.29 3.3. ]
[4.4, 5.5- 6.6/ ]
[7.7: 8.8<> ]
Modify text submenu
The first line shows which camera’s text identification is in the process of being
modified. The next line shows the text inserted so far. The flashing # cursor
shows the insertion point for other characters, if desired.
The text insertion method is that commonly used for mobile phones. Pressing
the
key will select the letter ‘A’; if is pressed again within one second
the letter ‘B’ will be selected, and pressing
again will select ‘C’. After one
second’s wait the choice will be accepted and the # cursor will move forward by
one position.
and can be used to select the character sets: “upper case”, “lower
case”, “numeric/symbols”.
Other characters are selected in the same way: for example ‘S’ is obtained by
pressing the
key 4 times. The number ‘9’ is obtained by selecting the
“numeric/symbols” set and pressing
twice.
deletes the last character inserted and adds a space to the inserted
text.
When insertion has been completed, press
to return to the previous menu.
[ALARM NO.1 5]
[----------------------------]
[ 1.Type: Normally Open ]
[ 2.Reset: Cont ]
[ 3.Relay activation: YES ]
[ 4.Buzzer activation: NO ]
[ 5.Acknowledge: 1,2 ]
[ 6.Action: CO4:MO2,R01:P03 ]
[ ]
[INC.Next Alarm ]
[DEC.Previous Alarm ]
[SEQ.End ]
Alarms submenu
The matrix is provided with an alarm contact for each input. For further details
see section 4.2 Alarms.
The alarm contact number being modified is shown on the first line; change the
number by pressing
and .
Press
to select the alarm type (normally open, normally closed, not used).
Press
to enter the submenu for defining Reset. Press and to
enable/disable relay closure and for buzzer enabling when the alarm is active.
Press
to enter the submenu for defining alarm recognition.
Press
to define the action on alarm. Press to return to the previous
menu.
[ALARM NO.1 RESET 5.2]
[----------------------------]
[ 1.Momentary: NO ]
[ 2.Keyboard : YES ]
[ 3.External : YES ]
[ ]
[ -.Time: After 2 seconds ]
[ CLEAR.< ENTER.> ]
[ ]
[INC.Next Alarm ]
[DEC.Previous Alarm ]
[SEQ.End ]
Reset Alarms submenu
Press to define the alarm type (continuous or impulsive). Press and
to enable/disable reset by keyboard or by external impulse.
Press
and to enable and change reset time.
Press
/ to pass to definition of the next/previous alarm. Press to
return to the previous menu.
[ALARM 1 ACKNOWLEDGE 5.5]
[----------------------------]
[ 1.Output 1: YES ]
[ 2.Output 2: NO ]
[ ]
[ ]
[ ]
[ ]
[INC.Next Alarm ]
[DEC.Previous Alarm ]
[ ]
[SEQ.End ]
Alarm recognition submenu
It is possible for each alarm to be recognised by each output video (or not). If
an alarm is not recognised the functioning of an output will be unchanged by
alarm activation, even if keyboard DCJ, DCK or DCT (when connected) will
display a warning message for the abnormal situation.
Press
.. to enable/disable alarm recognition for each output.
Press
/ to pass to definition of the next/previous alarm. Press to
return to the previous menu.
