GB
General notice (liability): the details of this technical documents serve for description. Consents regarding the availability of certain features or
regarding a certain purpose always require a special written agreement.
Page 27 GB 11 Right reserved to make technical changes!
11. Scale Drawings
890
980
370
470
47,5
45
42,5
46
405
450
570
740
655
833 500
450
480
440
117
117
437,5
485
42,5
46
Unit fits snugly to
ceiling element
Unit fits snugly to
ceiling element
Construction size 1 ceiling cut-out 570 x 405 mm
Construction size 2, ceiling cut-out 740 x 450 mm
Defrost water drainage
Defrost water drainageNetzzuleitung
Power supply
