12. Technical Data
CT 0900 CT 1200 CT 1500 CT 2000 CT 3000 FT 0700 FT 1000 FT 1200 FT 1500
Coldroom temperature +20°C to -5°C -5°C to -25°C
Power use [W]
1)
950 1150 1450 1800 2600 600 800 1100 1400
Allowable ambient temperature
+2°C to +40°C
economical range +2°C to +25°C
Construction size 1 2 1 2
Dimensions L x W x H 890 x 655 x 370 980 x 833 x 470 890 x 655 x 370 980 x 833 x 470
Dimensions of ceiling cut-out 405 x 570 450 x 740 405 x 570 450 x 740
Height of air jet in coldroom 117 mm
Total weight (kg) 62,5 67 67,5 97,5 110 70,5 96 97 114,5
Weight of machine part (kg) 43 47,5 48 67,5 80 51 66 67 84,5
Weight of insulating cover (kg) 10 15 10 15
Weight of evaporator fan unit (kg) 9,5 15 9,5 15
Power supply, frequency 230V +5/-10% / 50Hz
Fuses 16 A tr.
Length of power cable 4,5 m
Power usage [W]
1)
650 840 930 1400 2000 700 1030 1300 1990
Noise level
2)
40 41 42 43 46 41 43 43 44
Use Business
Protective class IP22
Type of sealing Fully hermetic
Injection technology Thermostatic injection valve
Defrosting Electric
Power usage defrostheating [W] 650 800 650 800
Refrigerant R404A
Volume of refrigerant [kg] 0,85 1,2 1,3 1,3 1,6 1,15 1,4 1,5 2,0
Switch-off point Pressostat (bar) 28
Max. pressure low pressure side [bar] 9
Area of evaporation [m²] 5,41 8,66 3,36 6,43
Fin separation, evaporator (mm) 4 5 7
Evaporation fan
3)
1 x 250 mm ø
1400 n-1
2 x 250 mm ø
1400 n-1
1 x 250 mm ø
1400 n-1
2 x 250 mm ø
1400 n-1
Power usage, evaporation fan [W] 40 80 40 80
Throwing distance evaporation fan [m]
3)
5656
Condenser area [m²] 5,22 10,25 8,46 15,69 10,25 8,46 15,69
Fin separation, condenser [mm] 2,2
Condenser fan 250 mm ø /1400 n-1
350 mm ø /
1400 n-1
250 mm ø
1400 n-1
350 mm ø /1400 n-1
Power Usage, condenser fan [W] 40 140 40 140
Flow volume, condenser [m³/h] 600 520 860 760 520 860 760
Controls Controls on unit or with remote control
Length of power cord, remote control 5m standard, 15m maximum length, on request
1) Power requirements for CT units at +5°C coldroom and +32°C ambient temperature, for FT units at –18°C coldroom and +32°C
ambient temperature.
2) A-valued equivalent noise level, measured in 10m intervals at nominal operation in the area of installation. Depending on room
conditions and position, values may be reached above the given noise levels.
3) The units can be supplied with evaporator fans with a rotational speed of 2800 n. This increases the throw distance by 2m.
This also increases the noise level in the coldroom.
