Hang the unit on the storage cell wall while pushing
against it from the outside.
Slide the holding angle against the inside cell wall and
tighten it securely with one or two bolts.
Loosen the locking screws (2 ea.) on the front access
cover.
Pull the front panel at the bottom a little bit forward
then push it upwards and take it off by pulling it forward
again.
Units without a
display have two
additional screws on
the front cover
