Viessmann GC1 Installation And Service Instructions

104
Commissioning
Matching the coding addresses to the system version (cont.)
Address
Setting of
08 Units and tens of the determined maximum output;
e.g. max. output: 225kW select: 25
Values up to and including 199 kW can be entered directly.
09 Hundreds of the determined maximum output;
e.g. max. output: 225kW here: 2
15 Determined run time in seconds
0A Relationship between base output and max. output in percent; e.g.
Base output: 72 kW
Max. output: 225 kW
72kW
225kW
@ 100% + 32%
05 Relationship between partial output and max. output in percent; e.g.
Partial output: 171 kW
Max. output: 225 kW
171kW
225kW
@ 100% + 76%
Checking outputs (actuators) and sensors
Relay test
1. Press K and d simultaneously
for approx. 2s.
Relay test is activated.
2. Control relay outputs
with a or b.
3. Press d.
Relay test is completed.
5862730GB
