68
Installation
Connecting an actuat
or with thr
ee−point output
Use as:
H
But
terfly valve
H
Mixer motor
H
Three−way mixing valve
|
Open
~
Closed
Rated v
oltage:
230V~
Rated cur
rent:
max. 0.2 (0.1) A
Recommended
connecting
cable:
H05VV−F4G 0.75 mm
2
or
H05RN−F4G 0.75 mm
2
Run−time:
5 to 199s,
adjustable via coding
address"40"
(delivered condition
125s)
