87
Installation
Making the L
ON
connection
The V
iessmann L
ON system is designed for "Line" BUS topology
, i.e. with
terminators at both ends.
Connection with Viessmann L
ON cable
A
Control unit or Vitocom
B
L
ON cable
C
T
erminator
Connection with
H
Viessmann L
ON cable and
H
Viessmann L
ON coupling
A
Control unit or Vitocom
B
L
ON cable (max. 3 cables
between 2 devices)
C
T
erminator
D
L
ON coupling
5862730GB
7 m
7 m
C
BB
C
A
A
A
7 m
C
B
C
7 m
B
D
7 m
B
D
7 m
B
D
D
7 m
B
A
A
A
7 m
B
86
88
