Viessmann Solar-Divicon PS10 - Pump curves

13
3-stage circulation pump
0 1 2 3
Pump rate in m³/h
Head
0
10
20
30
40
D
50
60
0.5 1.5 2.5
A
0
16.7
33.2 508.3
25
41.7
Pump rate in l/min
C
B
kPa mbar
0
100
200
300
400
500
600
A
Pressure drop curve
B
Head at output stage I
C
Head at output stage II
D
Head at output stage III
Pump curves
5773 841 GB
