Viessmann Solar-Divicon PS10 - Specification; Parts List for Solar-Divicon, type PS10

16
Type PS10, P10 PS10, P10 PS20, P20
Wilo circulation pump ST15/6ECO PARA 15/7.0 PARA 15/7.5
Multi stage
circulation
pump
HE circulation pump with
PWM control
Rated voltage V~ 230 230 230
Power consumption
■ Output stage I W 36 — —
■ Output stage II W 43 — —
■ Output stage III W 49 — —
■ Min. W — 3 3
■ Max. W — 45 73
Flow rate indicator l/min 1 to 13 1 to 13 5 to 35
Safety valve (solar) bar 6 6 6
Max. operating temperature °C 120 120 120
Max. operating pressure bar 6 6 6
Connections (locking ring fit-
ting/double O-ring)
■ Solar circuit mm 22 22 22
■ Expansion vessel mm 22 22 22
Parts list for Solar-Divicon, type PS10
Without solar control unit
Pos. Part
0001 Insulation shell
0002 Gasket set
0003 Type plate
0004 Circulation pump connecting cable, 230 V~
0005 Fixings
0006 Ball valve, return, DN 15
0007 Safety assembly
0008 Circulation pump
0009 Flow rate indicator
0010 Cover
0011 Mounting plate
0012 Thermometer, blue
0013 Thermometer, red
0014 Air separator, DN 15
Specification
5773 841 GB
