19
Pos. Part
0001 Insulation shell
0002 Solar control module, type SM1
0003 Type plate
0004 Ball valve, flow, DN 15
0005 Circulation pump connecting cable, 230 V~
0006 Fixings
0007 Screws 40 x 16 mm
0008 Cover
0009 Gasket set
0010 Ball valve, return, DN 15
0011 Safety assembly
0012 Circulation pump
0013 Flow rate indicator
0014 Mounting plate
0015 Thermometer, blue
0016 Thermometer, red
0017 Air separator, DN 15
0018 Ball valve handle, DN 15
0019 Retaining clip (5 pce)
0020 Cylinder temperature sensor
0021 Tee connection, flow
0022 Locking ring fitting (5 pce)
0023 Collector temperature sensor NTC
0024 Pressure gauge
0025 Circulation pump connecting cable, PWM (only for Solar-Divicon with HE cir-
culation pump)
0026 Screwless terminals
0027 Installation and service instructions
Parts list for Solar-Divicon, type PS10 (cont.)
5773 841 GB
