Viessmann VITOCELL 100-W Installation Instructions

11
Mount the bracket on the DHW cylinder or on the wall.
Fitting the expansion vessel to the DHW cylinder
Using the corrugated pipe supplied, connect the solar
expansion vessel to connection
N
(see page 6) of
safety assembly
R
.
x
Fig. 10
For further installation, observe dimension X.
Fitting the solar expansion vessel
5838641
