Viessmann VITOCELL 100-W Installation Instructions For Contractors

9
Heat meter (if installed)
1.
2.
Fig. 6
1. Disconnect the return pipe.
2. Disconnect the flow solar elbow.
450
154
238
Fig. 7
Trim the return pipe and insulation.
Hydraulic connection (on the solar side) (cont.)
5838620
