Viessmann VITOCONNECT OPTO2 - Display and Operating Elements

11
5840 711 - 01
Vitoconnect OPTO2 Installation and Operating
Display and Operating Elements
Commissioning
Legend
A Operating button
B Reset button
LED indicates the current operating status.
LED indicates the state of the communication with
the Wi-Fi and Viessmann server.
LED indicates the system functions and
communication with the heat generator
(maintenance mode, restart, update, error).
= Actuation area of the operating button A
