Viessmann Vitodens 100-E - Vertical Flue Systems

12
Vertical flue systems
q
o
o
r
p
s
t
u
t
Position Minimum spacing
mm
o From adjacent wall 300
p From adjacent opening window 1000
q From another terminal 600
r Minimum height 300
s Minimum distance measured perpendicular to
roof covering
400
t Beside or above an opening rooflight 600
u Below an opening rooflight 2000
Installations requirements
(cont.)
5780 223 GB
