Viessmann Vitodens 100-E - Installation in a Disused Chimney; Installation Requirements and Max Flue Length

36
Installation requirements
190
150
1200
300
D
C
B
A
90
A
Disused chimney
B
Balanced flue pipe for connecting
the flexible flue
C
Chimney connection plate
D
Vitodens
Installation in recesses below disused
chimneys. Recess height min.
1200 mm.
Installation in a disused chimney
5780 223 GB
