45
Roof construction in line with the flat
roof directive
C
D
E
F
D
G
B
H
A
A
Flat roof collar
B
Gravel ballast layer
C
Insulation layer
D
Aeration layer
E
Thermal insulation
F
Insulation
G
Ceiling
H
Flue pipe
Vertical outlet for pitched or flat roofs
(cont.)
