A Vitopend 200
! Outside temperature sen-
sor (only for weather-
compensated control
units)
sÖ A1 Heating circuit pump for a
heating circuit without
mixer A1 (connection via
extension)
B Temperature limiter for limiting
the maximum temperature of
underfloor heating systems
C Extension kit for one heating cir-
cuit with mixer M2
? M2 Flow temperature sensor
for heating circuit with
mixer M2
sÖ M2 Heating circuit pump for
heating circuit with
mixer M2
D Low loss header
? Flow temperature sensor for
low loss header
Required coding
Operation with LPG 1E:1
Internal extension (accessories) 53:2
Adjusting the heating curves (only for weather-compensated
control units)
The heating curves illustrate the rela-
tionship between the outside tem-
perature and the boiler water or flow
temperature.
To put it simply: The lower the outside
temperature, the higher the boiler
water or flow temperature.
The room temperature, again,
depends on the boiler water or the
flow temperature.
Settings in the delivered condition:
&
Slope = 1.4
&
Level = 0
Further details regarding the individual steps (cont.)
