Viessmann Vitoplex 100 PV1 Installation Instructions

10
Side panels and burner cables
4x
3.9 x 9.5
4x
4.
5.
1.
2.
A
3.
B
lÖ
fA
Fig. 9
A
Side panel, front right
B
Vitoplex 100 logo
Note
Provide burner cables on site if they are not supplied.
The inclusion of burner cables in the standard delivery
depends on which control unit is being supplied.
Note
Route the burner cables
fA
and
lÖ
along the side of
the boiler where the boiler door hinges are located.
Fitting the thermal insulation (cont.)
5592 753 GB
