1 Rawl plug S10
2 Washer
3 Hexagon screw 8x70 mm
qQ Clamping bracket
qW T-slot bolt
qE Washer
qR Hexagon nut
qT Mounting rail
qZ Mounting rail with tube holder
qU Retaining plate
wP Connecting chamber
wQ Va cuum tube
wW Retaining rubber
Accessories for one collector array
wE Connecting pipe
wR Retaining clip
Connection set:
wT Connecting pipe (short)
wZ Connecting pipe (long)
wU Profile clip
wI Locking ring fitting (elb ow 90°),
7 22 mm
wO Support sleev e
eP U-pipe
eQ Thermal insulati on cap
eW Fixing screws
Accessories for a solar heating
system
wO Support sleeve
eE Lockingringfitting(tee),
7 22 mm
eR Sensor well
eT Strain relief fitting
eZ Thermal insulation
Protection against slippage
Installation
height above
ground level
m <8 8-20 20-100
Type SD2 2 m
2
3m
2
2m
2
3m
2
2m
2
3m
2
FootA kg/piece2233446566 98
FootB kg/piece2639466967101
Protection against lifting
Installation
height above
ground level
m <8 8-20 20-100
Type SD2 2 m
2
3m
2
2m
2
3m
2
2m
2
3m
2
FootA kg/piece1522314648 72
FootB kg/piece1827324948 73
Installation on flat roofs (cont.)
32
5862 788 GB
