3. Fit the tee onto the flow connec-
tor.
4. Insert the sensor well into the tee,
holding the tee tightly.
5. Insert the strain relief fitting into
the sensor wel l.
6. Insert the collector temperature
sensor as far as possible into th e
sensor well and secure w ith PG
thread.
7. Insert the U-pipe as far as possi-
ble, then secure with profile clips.
8. Insert the support sleeves into the
pipework of the solar circuit.
Make the connection between the
collector array and pipework of
the solar heati ng circuit.
9. Check the system p ressure and
test for leaks.
"Vitosol" service instr uc-
tions.
10. Fit the thermal insulation and join
its cut face s wi th adhesiv e.
11. Fit and secure the thermal insula-
tion cap.
Installation
!
Please note
Incorrect installation can lead to collector damage.
Use only gunmetal and brass fittings and copper pipes for the installa-
tion.
Use hemp only in conjunction with pressure and temperature-resistant
sealants (e.g. Viscotex Solarpaste from Locher, CH-9450 Altstätten).
Never step onto solar panels.
Never s older near or on the col lector.
Water connections (cont.)
51
